MANIFOLD &VALVE

Name: MANIFOLD &VALVE
Brand: PRATIK CABLETRAY PRIVATE LIMITED
Price: 2890.0 INR
Availability: InStock

Price 2890.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

MANIFOLD &VALVE Specification

Surface Finish
HDG

Material
Other

Standard Thickness
1.2 3 Millimeter (mm)

Length
2.5 - 4 Meter (m)

Color
Other

Warranty
6-12 Month

MANIFOLD &VALVE Trade Information

Minimum Order Quantity
1 Number

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

MANIFOLD &VALVE About

A manifold valve integrates multiple valve functions (isolation, bleeding, equalization) into a single compact body, controlling, directing, and regulating fluid or gas flow in hydraulic, pneumatic, and instrumentation systems. By consolidating these components, they reduce space, leakage points, and installation costs, ensuring safe, efficient operation without full system shutdowns.

Key Features & Components

Integrated Design: Combines block, bleed, and needle valves into one unit.
Materials: Constructed from durable materials like Stainless Steel (ASTM A479/A182), Carbon Steel, Monel, Inconel, and Titanium.
Valve Types: Primarily uses needle or ball valves for precise control.
Configurations: Available in 2-way (static pressure), 3-way, and 5-way (differential pressure) configurations, offering, among other things, equalization capabilities.
Safety Features: Often includes blow-out proof needles, locking pins for bonnets, and anti-tamper designs.

Main Functions

Isolation: Safely separates process media from instruments.
Equalization/Calibration: Allows for safe, on-site pressure transmitter calibration without stopping production.
Bleeding/Venting: Safely releases pressure or drains fluids.
Distribution: Distributes fluids or gases to multiple outlets from a single source.

Common Applications

Process Instrumentation: Used with transmitters and gauges in oil & gas and chemical industries.
Hydraulic & Pneumatic Systems: Controls actuators, cylinders, and motors in industrial machinery.
Power & HVAC: Manages high-pressure steam in boilers and regulates temperature/pressure in HVAC systems.

Advantages

Reduced Leakage Points: Fewer pipe connections enhance safety.
Space Saving: Ideal for tight, complex piping setups.
Easy Maintenance: Enables instrument removal without breaking into the main process line.
